| PartNumber | TM123XDHP90 |
| Brand | TIANMA |
| Size | 12.3 |
| Application | Industrial Outdoor High Brightness Automotive Display |
| Resolution | 1920(RGB)×720, 166PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 10S4P |
| Interface | LVDS |
| Panel Brand | TIANMA |
| Panel Model | TM123XDHP90 |
| Panel Size | 12.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 292.32(W)×109.62(H) mm |
| Bezel Opening | - |
| Outline Size | 311(W)×130(H) ×15.7(D) mm |
| Surface | Antiglare (Haze 28%) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | - |
| Display Mode | SFT, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 98% sRGB |
| Lamp Type | 10S4P WLED , 10K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 490g (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins FPC |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
