| PartNumber | TM150TDSG59 |
| Brand | AVIC |
| Size | 15.0 |
| Application | Industrial |
| Resolution | 1024(RGB)×768, XGA, 85PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 600:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AVIC |
| Panel Size | 15.0" |
| Display Area | 304.128(W)×228.096(H) mm |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 262K/16.7M 60% NTSC |
| Frequency | 60Hz |
| Panel Weight | - |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
| Panel Model | TM150TDSG59 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 3/5 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 30K hours |
| Touch Screen | Without |
