| PartNumber | TV070WSM-NM0 |
| Brand | BOE |
| Size | 7.0 |
| Application | Pad & Tablet |
| Resolution | 1024(RGB)×600, WSVGA, 169PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | BOE |
| Panel Model | TV070WSM-NM0 |
| Panel Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 153.6(W)×90(H) mm |
| Bezel Opening | - |
| Outline Size | 161.16(W)×100.97(H) ×4.8(D) mm |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 50% NTSC |
| Lamp Type | WLED , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 90.0g (Max.) |
| Signal Interface | MIPI (4 data lanes) , 40 pins Connector |
| Input Voltage | 1.8/3.3/9/19/-7V (Typ.)(VDD1/VDD3/AVDD/VGH/VGL) |
| Environment | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 85 °C |
