| PartNumber | TV101QUM-N00 |
| Brand | BOE |
| Size | 10.1 |
| Application | PAD |
| Resolution | 3840(RGB)×2160 , UHD |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | BOE |
| Panel Model | TV101QUM-N00 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | ADS, Normally Black, Transmissive |
| Active Area | 222.912×125.388 mm |
| Outline | 231.6×140.9 mm |
| Surface | |
| Contrast Ratio | 1500:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE1931100% |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 8S6PWLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 40 pins |
| Input Voltage | 3.3V (Typ.) |
