| PartNumber | TV105WUM-AS0 |
| Brand | BOE |
| Size | 10.5 |
| Application | Pad & Tablet |
| Resolution | 1200×1920 |
| Composition | Assembly , a-Si TF |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | 4 strings WLED , No Driver |
| Interface | MIPI |
| Manufacturer | BOE |
| Screen Size | 10.5 inch |
| Pixel Number | 1200(RGB)×1920 (WUXGA) 215PPI |
| Active Area(mm) | 141.3 × 226.08 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 480 cd/m² (Typ.) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 92% DCI-P3 |
| Mass | 216g (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | MIPI (4 data lanes) , 34 pins Connector |
| Voltage Supply | 1.8/5.8/-5.8V (Typ.)(VDD/VSP/VSN) |
| Max. Ratings | Storage Temp.: -55 ~ 125 °C Operating Temp.: -20 ~ 85 °C |
| Model Name | TV105WUM-AS0 |
| Screen Type | Assembly , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 156.18 × 255.06 × 4.44 (H×V×D) |
| Treatment | Hard coating |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | - |
| Used for | Pad & Tablet |
| Touchscreen | PCAP |
