| PartNumber | TX11D201VM0BAA |
| Brand | KOE |
| Size | 4.2 |
| Application | Automotive Display |
| Resolution | 480×272 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | Parallel |
| Model | TX11D201VM0BAA |
| Diagonal Size | 4.2 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 131PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 92.88(H)×52.632(V) mm |
| Outline Dim. | 102.5(H)×69(V) ×15.5(D) mm |
| Bezel Area | 95.28(H)×55.07(V) mm |
| Treatment | Antiglare, Hard coating (2H) |
| Luminance | 750 cd/m² (Typ.) |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M 65% NTSC |
| Light Source | WLED [6S1P] , 50K hours , With LED Driver |
| Weight | 97.0g (Typ.) |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 8-bit) , 68 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
