| PartNumber | TX18D211VM0BAA |
| Brand | KOE |
| Size | 7.0 |
| Application | Industrial Outdoor High Brightness Automotive Display |
| Resolution | 800(RGB)×480, WVGA, 133PPI |
| Composition | LTPS TFT-LCD, LCM |
| Brightness | 1200 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | KOE |
| Panel Model | TX18D211VM0BAA |
| Panel Size | 7.0" |
| Panel Type | LTPS TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 152.4(W)×91.44(H) mm |
| Bezel Opening | 156.2(W)×94.5(H) mm |
| Outline Size | 167.7(W)×109.5(H) ×20.3(D) mm |
| Surface | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 262K 73% NTSC |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 219g (Typ.) |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
