| PartNumber | TX23D12VM0CAA |
| Brand | KOE |
| Size | 9.0 |
| Application | IA |
| Resolution | 800(RGB)×480 , WVGA |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | TTL |
| Panel Brand | HITACHI |
| Panel Model | TX23D12VM0CAA |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 9.0 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 195×117 mm |
| Outline | 236×135 mm |
| Surface | Antiglare |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193160% |
| Response Time | 13/17 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | CMOS (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.)(VDD) |
