| PartNumber | V320BJ8-Q01 |
| Brand | Innolux |
| Size | 32.0 |
| Application | TV Sets |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | |
| CR | 3000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | LVDS |
| Model | V320BJ8-Q01 |
| Diagonal Size | 32.0 inch |
| Type | a-Si TFT-LCD, CELL |
| Pixel Format | 1366×768(RGB) [WXGA] 49PPI |
| Configuration | RGB Horizontal Stripe |
| Active Area | 697.685(H)×392.256(V) mm |
| Outline Dim. | 716.2(H)×410(V) ×1.35(D) mm |
| Bezel Area | - |
| Treatment | Antiglare (Haze 2%) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 8.5 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | MVA, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 6.2% (Typ.)(with Polarizer) |
| Support Color | 16.7M 70% NTSC |
| Light Source | No B/L |
| Weight | 896g (Typ.) |
| Designed For | TV Sets |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | COF Built-in 1 source chips |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
