| PartNumber | V500HJ1-PE8 Rev.C3 |
| Brand | Chimei Innolux |
| Size | 50 |
| Application | Transparent Display |
| Resolution | 1920(RGB)×1080, FHD, 44PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 5000:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | LVDS |
| Panel Brand | Chimei Innolux |
| Panel Size | 50" |
| Display Area | 1095.84(W)×616.41(H) mm |
| Outline Size | 1112.32(W)×631.61(H) ×1.31(D) mm |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥20) |
| Best View on | Symmetry |
| Glass Depth | 0.50+0.50 mm |
| Display Colors | 16.7M 70% NTSC |
| Frequency | 60Hz |
| Driver IC | COF Built-in 6 source + 4 gate chips |
| Panel Weight | 1.99±0.19Kgs |
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | V500HJ1-PE8 Rev.C3 |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare (Haze 1%), Hard coating (3H) |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| Display Mode | Super MVA, Normally Black, Transmissive |
| Response Time | 8.5 (Typ.)(G to G) |
| Transmissivity | 5.6% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
| LC500DUE-SFR1 | LG Display | 50 | 1920×1080 |
| LC500EUD-FFF3 | LG Display | 50 | 1920×1080 |
| T500HVN04.1 CELL | AUO | 50 | 1920×1080 |
| T500HVN04.5 CELL | AUO | 50 | 1920×1080 |
| T500QVN01.1 CELL | AUO | 50 | 3840×2160 |
| V500HJ1-L01 | Innolux | 50 | 1920×1080 |
| V500HJ1-LE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE8 | Innolux | 50 | 1920×1080 |
| V500HK1-LS6 Rev.C7 | Innolux | 50 | 1920×1080 |
