V650DJ6-Q02 Rev.E1


Brand
Innolux
Size
65
Application
TV Sets
Resolution
3840×2160
Composition
CELL ,   a-Si TFT-LC
Brightness
CR
5000:1
Colors
1.07B
Backlight
No
Interface
In Stock
2278
Specifications
PartNumber V650DJ6-Q02 Rev.E1
BrandInnolux
Size65
ApplicationTV Sets
Resolution3840×2160
CompositionCELL ,   a-Si TFT-LC
Brightness
CR5000:1
Colors1.07B
BacklightNo B/L
Interface
ManufacturerInnolux
Screen Size65 inch
Pixel Number3840(RGB)×2160   (UHD)  68PPI
Active Area(mm)1428.48 × 803.52 (H×V)
Bezel Area(mm)-
Luminance0 (cd/m²)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Good View atSymmetry
Glass Thickness0.50+0.50 mm
Color Depth1.07B   74% NTSC
Mass3.60±0.18Kgs
Refresh Rate60Hz
Model NameV650DJ6-Q02 Rev.E1
Screen TypeCELL ,   a-Si TFT-LCD
ArrangementRGB Vertical Stripe
Outline(mm)1438.48 × 815.02 × 1.33 (H×V×D)
TreatmentAntiglare (Haze 1%), Hard coating (3H)
Contrast Ratio5000 : 1 (Typ.) (TM)
Work ModeSuper MVA, Normally Black, Transmissive
Response9.5 (Typ.)(G to G) ms
Transmissivity5.14% (Typ.)(with Polarizer)
Used forTV Sets
TouchscreenWithout
Family Model
LC650DUF-FGF1 LG Display 65 1920×1080
LC650EQF-FJM1 LG Display 65 3840×2160
LC650EQF-PHF1 LG Display 65 3840×2160
LD650EUF-FHB1 LG Display 65 1920×1080
T645HW04 V0 CELL AUO 65 1920×1080
T650HVD01.0 AUO 65 1920×1080
T650HVN06.0 AUO 65 1920×1080
T650QVF04.0 AUO 65 3840×2160
T650QVJ02.0 AUO 65 3840×2160
V645HQ1-LS1 Innolux 65 1920×1080
