V650HP1-LS6 Rev.E

V650HP1-LS6 Rev.E
V650HP1-LS6 Rev.E
V650HP1-LS6 Rev.E
V650HP1-LS6 Rev.E thumb V650HP1-LS6 Rev.E thumb V650HP1-LS6 Rev.E thumb
Brand
Innolux
Size
65
Application
LCTV
Resolution
1920×1080
Composition
LCM
Brightness
350
CR
5000:1
Colors
1.07B
Backlight
WLED
Interface
LVDS
In Stock
10895
Specifications
PartNumber V650HP1-LS6 Rev.E
BrandInnolux
Size65
ApplicationLCTV
Resolution1920(RGB)×1080 , FHD
CompositionLCM
Brightness350 cd/m² (Typ.)
CR5000:1
Colors1.07B
BacklightWLED
InterfaceLVDS
Panel BrandCHIMEI INNOLUX
Panel ModelV650HP1-LS6 Rev.E
Panel Type a-Si TFT-LCD , LCM
Panel Size65 inch
Display ModeSuper MVA, Normally Black, Transmissive
Active Area1428.48×803.52 mm
Outline1450.5×828.52×30.8 mm
SurfaceAntiglare (Haze 1%), Hard coating (3H)
Contrast Ratio5000:1 (Typ.)
Display Colors1.07B (8-bit + Hi-FRC), CIE193172%
Response Time6.5 (Typ.)(G to G)
Viewing Angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequency120Hz
Lamp Type4 stringsWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 102 pins
Input Voltage12.0V (Typ.)
