| PartNumber | V750DJ1-Q02 |
| Brand | Innolux |
| Size | 75 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 59PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | V-by-One |
| Panel Brand | Innolux |
| Panel Size | 75" |
| Display Area | 1650.24(W)×928.26(H) mm |
| Outline Size | 1662.24(W)×941.96(H) ×1.32(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | 0.50+0.50 mm |
| Display Colors | 1.07B 72% NTSC |
| Frequency | 60Hz |
| Driver IC | COF Built-in 24 source + 16 gate chips |
| Panel Weight | 4.66±0.23Kgs |
| Signal Interface | V-by-One 8 lane , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | V750DJ1-Q02 |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare (Haze 1%), Hard coating (3H) |
| Contrast Ratio | 5000:1 (Typ.) (TM) |
| Display Mode | Super MVA, Normally Black, Transmissive |
| Response Time | 9.5 (Typ.)(G to G) |
| Transmissivity | 5.0% (Typ.)(with Polarizer) |
| Lamp Type | No B/L |
| Touch Screen | Without |
