| PartNumber | V750DK2-Q01 |
| Brand | Innolux |
| Size | 75 |
| Application | TV Sets |
| Resolution | 3840×2160 |
| Composition | CELL, a-Si TFT-LCD |
| Brightness | |
| CR | 5000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Manufacturer | Innolux |
| Model Name | V750DK2-Q01 |
| Screen Size | 75 inch |
| Screen Type | CELL, a-Si TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 59PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1650.24 × 928.26 (H×V) |
| Outline(mm) | 1662.24 × 941.96 × 1.32 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 5000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 6.5 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | Super MVA, Normally Black, Transmissive |
| Glass Thickness | - |
| Transmissivity | 5.0% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 72% NTSC |
| Mass | 4.62±0.23Kgs |
| Used for | TV Sets |
| Refresh Rate | - |
| Touchscreen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
