| PartNumber | VLT190-SBL-SXGA-148.5 |
| Brand | Vitrolight |
| Size | 15.9 |
| Application | Stretched Bar LCD Di |
| Resolution | 1280×505 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | VLT190-SBL-SXGA-148.5 |
| Diagonal Size | 15.9 inch (1/2 cut of 19.0") |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×505 86PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 375(H)×148.5(V) mm |
| Outline Dim. | 396(H)×172(V) mm |
| Bezel Area | 379(H)×152.5(V) mm |
| Treatment | - |
| Luminance | 410 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 5.5 (Typ.)(G to G) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED |
| Weight | - |
| Designed For | Stretched Bar LCD Digital Signage |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C - |
