| PartNumber | VLT270-SBL-FHD-168 |
| Brand | Vitrolight |
| Size | 24.4 |
| Application | Digital Signage Stretched Bar LCD |
| Resolution | 1920(RGB)×540, 81PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | Vitrolight |
| Panel Model | VLT270-SBL-FHD-168 |
| Panel Size | 24.4" (1/2 cut of 27.0") |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 597.6(W)×168(H) mm |
| Bezel Opening | - |
| Outline Size | 630(W)×200(H) mm |
| Surface | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 3.8 (Typ.)(G to G) |
| Display Colors | 16.7M 72% NTSC |
| Lamp Type | WLED |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | - |
| Signal Interface | LVDS (2 ch, 8-bit) Connector |
| Environment | Operating Temp.: 0 ~ 50 °C ; - |
