| PartNumber | WB014ZNM-N00 |
| Brand | BOE |
| Size | 1.39 |
| Application | Wearable Round Display |
| Resolution | 454(RGB)×454, 325PPI |
| Composition | AM-OLED , OLED |
| Brightness | 350 cd/m² (Typ.) |
| CR | 20000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | MIPI |
| Panel Brand | BOE |
| Panel Size | 1.39" |
| Display Area | 35.412(W)×35.412(H) mm |
| Outline Size | 38.212(W)×39.372(H) mm |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 103% NTSC |
| Frequency | 60Hz |
| Driver IC | COG Built-in RM67162FI |
| Panel Weight | 2.64g |
| Signal Interface | MIPI (1 data lane) , 20 pins Connector |
| Input Voltage | 1.8/3.0/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| Panel Model | WB014ZNM-N00 |
| Panel Type | AM-OLED , OLED |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | With Polarizer |
| Contrast Ratio | 20000:1 (Typ.) (TM) |
| Display Mode | - |
| Response Time | 3 (Max.)(Tr+Td) |
| Lamp Type | self |
| Touch Screen | Without |
