| PartNumber | WEH004002AG |
| Brand | Winstar |
| Size | 5.9 |
| Application | Instruments & Meters |
| Resolution | 40×26 |
| Composition | PM-OLED, OLED |
| Brightness | |
| CR | |
| Colors | Mono(Green) |
| Backlight | self |
| Interface | CPU/SPI |
| Panel Brand | Winstar |
| Panel Model | WEH004002AG |
| Panel Size | 5.9" |
| Panel Type | PM-OLED, OLED |
| Display Format | 40 characters × 2 lines, 6PPI |
| Font Format | 5×8 dots |
| Character Size | 3.05×5.55(W×H) mm |
| Character Pitch | 3.72×6.3(W×H) mm |
| Display Area | 148.13(W)×11.85(H) mm |
| Bezel Opening | 154.4(W)×16.5(H) mm |
| Outline Size | 182(W)×38.5(H) ×9.3(D) mm |
| Surface | - |
| Viewing Angle | - |
| Display Mode | - |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | Mono(Green) |
| Lamp Type | self |
| Frequency | - |
| Touch Screen | Without |
| Driver IC | COBBuilt-in WS0010 |
| Panel Weight | - |
| Signal Interface | CPU/SPI , 16 pins Pad |
| Input Voltage | 5.0V (Typ.) |
