| PartNumber | WEO006432AW |
| Brand | Winstar |
| Size | 0.49 |
| Application | Wearable |
| Resolution | 64×32, 145PPI |
| Composition | PM-OLED , OLED |
| Brightness | |
| CR | |
| Colors | Mono(White) |
| Backlight | self |
| Interface | I²C |
| Panel Brand | Winstar |
| Panel Size | 0.49" |
| Display Area | 11.18(W)×5.58(H) mm |
| Outline Size | 14.5(W)×11.6(H) ×1.46(D) mm |
| Viewing Angle | - |
| Best View on | Symmetry |
| Display Colors | Mono(White) |
| Frequency | - |
| Driver IC | COG Built-in SSD1306BZ |
| Panel Weight | - |
| Signal Interface | I²C , 14 pins FPC |
| Input Voltage | 3.0/7.5V (Typ.)(VDD/VCC) |
| Environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C |
| Panel Model | WEO006432AW |
| Panel Type | PM-OLED , OLED |
| Pixel Format | Rectangle |
| Bezel Opening | 12.58(W)×6.58(H) mm |
| Surface | - |
| Display Mode | - |
| Response Time | - |
| Lamp Type | self |
| Touch Screen | Without |
