| PartNumber | WEO012864AL |
| Brand | Winstar |
| Size | 1.54 |
| Application | Handheld & PDA I |
| Resolution | 128×64 |
| Composition | PM-OLED, OLED |
| Brightness | |
| CR | |
| Colors | Mono(Yellow) |
| Backlight | self |
| Interface | 8-bit |
| Model | WEO012864AL |
| Diagonal Size | 1.54 inch |
| Type | PM-OLED, OLED |
| Pixel Format | 128×64 92PPI |
| Configuration | Rectangle |
| Active Area | 35.05(H)×17.51(V) mm |
| Outline Dim. | 42.04(H)×23.03(V) ×1.55(D) mm |
| Bezel Area | 37.05(H)×19.52(V) mm |
| Treatment | - |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | - |
| Support Color | Mono(Yellow) |
| Light Source | self |
| Weight | - |
| Designed For | Handheld & PDA Instruments & Meters Comm Device Home Appliance Healthcare |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Built-in SSD1309ZC |
| Interface Type | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| Power Supply | 3.0/12.5V (Typ.)(VDD/VCC) |
| Environment | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
