| PartNumber | WEO012864KS |
| Brand | Winstar |
| Size | 2.7 |
| Application | Handheld & PDA Instruments & Meters |
| Resolution | 128×64, 52PPI |
| Composition | PM-OLED , OLED |
| Brightness | |
| CR | |
| Colors | Mono(Blue) |
| Backlight | self |
| Interface | 8-bit |
| Panel Brand | Winstar |
| Panel Size | 2.7" |
| Display Area | 61.41(W)×30.69(H) mm |
| Outline Size | 73(W)×41.86(H) ×2.15(D) mm |
| Viewing Angle | - |
| Best View on | Symmetry |
| Display Colors | Mono(Blue) |
| Frequency | - |
| Driver IC | COG Built-in SSD1309ZC |
| Panel Weight | - |
| Signal Interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 31 pins FPC |
| Input Voltage | 3.0V (Typ.) |
| Panel Model | WEO012864KS |
| Panel Type | PM-OLED , OLED |
| Pixel Format | Rectangle |
| Bezel Opening | 63.41(W)×32.69(H) mm |
| Surface | - |
| Display Mode | - |
| Response Time | - |
| Lamp Type | self |
| Touch Screen | Without |
