| PartNumber | WF39ATIASDNT0 |
| Brand | Winstar |
| Size | 3.9 |
| Application | Industrial Stretched Bar LCD |
| Resolution | 480(RGB)×128, 128PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | - |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | Winstar |
| Panel Size | 3.9" (1/2 cut of 4.3") |
| Display Area | 95.04(W)×25.34(H) mm |
| Outline Size | 105.5(W)×40.64(H) ×4.65(D) mm |
| Viewing Angle | 70/70/50/50 (Typ.)(CR≥10) |
| Best View on | 12 o'clock |
| Display Colors | 16.7M |
| Frequency | - |
| Weight | - |
| Panel Model | WF39ATIASDNT0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 97.8(W)×27.1(H) mm |
| Surface | Antiglare |
| Contrast Ratio | - |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | - |
| Lamp Type | WLED , Without Driver |
| Touch Screen | 4-wire Resistive Touch |
