| PartNumber | WF39BSQASDNN0 |
| Brand | Winstar |
| Size | 3.9 |
| Application | Industrial Stretched |
| Resolution | 480×128 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | 7S2P WLED , 50K hours , No Driver |
| Interface | |
| Manufacturer | Winstar |
| Model Name | WF39BSQASDNN0 |
| Screen Size | 3.9 inch (1/2 cut of 4.3") |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 480×128(RGB) 128PPI |
| Arrangement | RGB Horizontal Stripe |
| Active Area(mm) | 95.04 × 25.34 (H×V) |
| Outline(mm) | 105.5 × 37 × 3.25 (H×V×D) |
| Bezel Area(mm) | 97.04 × 27.34 (H×V) |
| Treatment | Antiglare |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/65/65 (Typ.)(CR≥10) |
| Response | 10/15 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M |
| Mass | - |
| Used for | Industrial Stretched Bar LCD Automotive Display |
| Refresh Rate | - |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 80 °C |
