| PartNumber | WF57STIACDNN0 |
| Brand | Winstar |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 320×240, QVGA, 70PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | Grayscale |
| Backlight | WLED |
| Interface | 8/16-bit |
| Panel Brand | Winstar |
| Panel Size | 5.7" |
| Display Area | 115.2(W)×86.4(H) mm |
| Outline Size | 160(W)×109(H) ×7.5(D) mm |
| Viewing Angle | - |
| Best View on | 12 o'clock |
| Display Colors | Grayscale |
| Frequency | - |
| Panel Weight | - |
| Signal Interface | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Model | WF57STIACDNN0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | Rectangle |
| Bezel Opening | 122.0(W)×92.0(H) mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | - |
| Lamp Type | WLED , Without Driver |
| Touch Screen | Without |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
