| PartNumber | WG12232K-YYH-N#A |
| Brand | Winstar |
| Size | 1.9 |
| Application | Industrial Instruments & Meters |
| Resolution | 122×32, 67PPI |
| Composition | STN-LCD , LCM |
| Brightness | - |
| CR | 3:1 |
| Colors | Monochrome |
| Backlight | YG-LED |
| Interface | |
| Panel Brand | Winstar |
| Panel Size | 1.9" |
| Display Area | 45.72(W)×11.97(H) mm |
| Outline Size | 59(W)×32.1(H) ×5.5(D) mm |
| Viewing Angle | 30/30/20/40 (Typ.)(CR≥2) |
| Best View on | 6 o'clock |
| Display Colors | Monochrome |
| Frequency | - |
| Weight | - |
| Panel Model | WG12232K-YYH-N#A |
| Panel Type | STN-LCD , LCM |
| Pixel Format | Rectangle |
| Bezel Opening | 52.0(W)×15.0(H) mm |
| Surface | - |
| Contrast Ratio | 3:1 (Typ.) (TM) |
| Display Mode | STN, Yellow/Green (Positive), Transflective |
| Response Time | 150/150 (Typ.)(Tr/Td) |
| Lamp Type | YG-LED , 50K hours , With LED Driver |
| Touch Screen | Without |
