| PartNumber | WS020ZVM-N30-6KP0 |
| Brand | BOE |
| Size | 2.0 |
| Application | Wearable Round Displ |
| Resolution | 640×572 |
| Composition | LTPS TFT-LCD, LCM |
| Brightness | |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Model | WS020ZVM-N30-6KP0 |
| Diagonal Size | 2.0 inch |
| Type | LTPS TFT-LCD, LCM |
| Pixel Format | 640(RGB)×572 327PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 49.728(H)×44.364(V) mm |
| Outline Dim. | 52.1(H)×49.8(V) mm |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Support Color | 16.7M 70% NTSC |
| Light Source | WLED [4S1P] , W/O Driver |
| Weight | - |
| Designed For | Wearable Round Display |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Interface Type | MIPI (1 data lane) , 30 pins Connector |
| Power Supply | 1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN) |
| Environment | Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
