| PartNumber | AC057VK04 |
| Brand | Mitsubishi |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 640(RGB)×480, VGA, 141PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 520 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | Parallel |
| Panel Brand | Mitsubishi |
| Panel Model | AC057VK04 |
| Panel Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 115.2(W)×86.4(H) mm |
| Bezel Opening | 118.1(W)×89.3(H) mm |
| Outline Size | 127(W)×100(H) mm |
| Surface | Antiglare, Hard coating (2H) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 4/12 (Typ.)(Tr/Td) |
| Display Colors | 262K 48% NTSC |
| Lamp Type | WLED , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 90.0g |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
