| PartNumber | AM-640480GJTNQW-TA0H |
| Brand | AMPIRE |
| Size | 5.7 |
| Application | IA |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 425 cd/m² (Typ.) |
| CR | 250:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AMPIRE |
| Panel Model | AM-640480GJTNQW-TA0H |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.7 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 115.2×86.4 mm |
| Outline | 127×98.43×9.84 mm |
| Surface | |
| Contrast Ratio | 250:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193150% |
| Response Time | 50 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| COM57H5M10XRC | ORTUSTECH | 5.7 | 640×480 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| G121SN01 V1 | AUO | 12.1 | 800×600 |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LM32019T | SHARP | 5.7 | 320×240 |
| LM80C209 | SHARP | 11.3 | 800×600 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| RGS24128022YR000 | RiTdisplay | 2.4 | 128×22 |
| TX18D41VM0EAA | KOE | 7.0 | 1024×600 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
| UG-6028GDEBF02 | WiseChip | 1.7 | 160×128 |
