| PartNumber | TX18D41VM0EAA |
| Brand | KOE |
| Size | 7.0 |
| Application | IA |
| Resolution | 1024(RGB)×600 , WSVGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | HITACHI |
| Panel Model | TX18D41VM0EAA |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 7.0 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 153.6×90 mm |
| Outline | 162.8×103.1×4.5 mm |
| Surface | |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193150% |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S3PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| Input Voltage | 3.3V (Typ.) |
