| PartNumber | AM-1024600K7TMQW-T19H |
| Brand | AMPIRE |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 1024×600 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 700:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 7.0 inch |
| Pixel Format | 1024(RGB)×600 [WSVGA] 169PPI |
| Active Area | 153.6(H)×90(V) mm |
| Luminance | 425 cd/m² (Typ.) |
| View Direction | 6 o'clock |
| Viewing Angle | 75/75/70/75 (Typ.)(CR≥10) |
| Support Color | 16.7M |
| Weight | TBD |
| Frame Rate | 60Hz |
| Model | AM-1024600K7TMQW-T19H |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 165.5(H)×104.44(V) ×10.81(D) mm |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Response Time | 20/20 (Typ.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED [5S3P] , 30K hours , With LED Driver |
| Designed For | Industrial |
| Touch Panel | PCAP |
| 70WVW1A | SII | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| A070XN01 V0 | AUO | 7.0 | 1024×768 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
