| PartNumber | AM-1024768FCTMQW-T00H |
| Brand | AMPIRE |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1200:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Model | AM-1024768FCTMQW-T00H |
| Diagonal Size | 10.4 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 123PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 210.4(H)×157.8(V) mm |
| Outline Dim. | 238.6(H)×175.8(V) mm |
| Luminance | 280 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14/11 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | Normally Black, Transmissive |
| Support Color | 262K/16.2M 57% NTSC |
| Light Source | WLED , 30K hours , With LED Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Interface Type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
| G104VN01 V1 | AUO | 10.4 | 640×480 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| LT104AC36000 | TOSHIBA | 10.4 | 1024×768 |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
