| PartNumber | AM-1024768V1TZQW-A0H |
| Brand | AMPIRE |
| Size | 8.4 |
| Application | Industrial |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | AM-1024768V1TZQW-A0H |
| Diagonal Size | 8.4 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 152PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 170.8(H)×128.1(V) mm |
| Outline Dim. | 203(H)×145.5(V) ×8(D) mm |
| Bezel Area | 174.15(H)×131.2(V) mm |
| Treatment | - |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Support Color | 16.7M |
| Light Source | WLED [6S6P] , 50K hours , With LED Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
