| PartNumber | AM-19201200B1TZQW-01-B |
| Brand | AMPIRE |
| Size | 10.1 |
| Application | Industrial Outdoor High Brightness |
| Resolution | 1920(RGB)×1200, WUXGA, 224PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | AMPIRE |
| Panel Size | 10.1" |
| Display Area | 216.806(W)×135.504(H) mm |
| Outline Size | 243.45(W)×155.2(H) ×9.61(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 53% NTSC |
| Frequency | 60Hz |
| Weight | - |
| Panel Model | AM-19201200B1TZQW-01-B |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 50K hours , Without Driver |
| Touch Screen | Without |
