| PartNumber | VVX10F002A00 |
| Brand | Panasonic |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1920(RGB)×1200 , WUXGA |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | Panasonic |
| Panel Model | VVX10F002A00 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | IPS, Normally Black, Transmissive |
| Active Area | 217.44×135.9 mm |
| Outline | 227.1×147.1×4.13 mm |
| Surface | Hard coating, Antireflection |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193150% |
| Response Time | 30 (Max.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S6PWLEDEmbedded (LED Driver) |
| Signal Interface | MIPI (4 data lanes), 40 pins |
| Input Voltage | 3.7V (Typ.) |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| N101L6-L0B | Innolux | 10.1 | 1024×600 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
| BP070WS1-200 | BOE | 7.0 | 1024×600 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
