| PartNumber | AM-800480L6TZQW-TN0H-I |
| Brand | AMPIRE |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 250:1 |
| Colors | 16.7M |
| Backlight | 3S4P WLED , 30K hours , No Driver |
| Interface | Parallel |
| Manufacturer | AMPIRE |
| Model Name | AM-800480L6TZQW-TN0H-I |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 188PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 108 × 64.8 (H×V) |
| Outline(mm) | 118.5 × 77.1 × 6.44 (H×V×D) |
| Bezel Area(mm) | 110.6 × 67.4 (H×V) |
| Treatment | - |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 250 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 15/35 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | Normally Black, Transmissive |
| Color Depth | 16.7M 52% NTSC |
| Mass | - |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | PCAP |
| Signal Type | Parallel RGB (1 ch, 8-bit) , FPC 45 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
