| PartNumber | AMS470GS16-1 |
| Brand | Samsung |
| Size | 4.7 |
| Application | MPH |
| Resolution | 720RG(BG)×1280 , WXGA |
| Composition | Assembly |
| Brightness | 300 cd/m² (Typ.) |
| CR | 3400:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | MIPI |
| Panel Brand | SAMSUNG |
| Panel Model | AMS470GS16-1 |
| Panel Type | AM-OLED , Assembly |
| Panel Size | 4.7 inch |
| Active Area | 57.96×103.04 mm |
| Outline | 66.36×131.8 mm |
| Surface | Hard coating |
| Contrast Ratio | 3400 : 1 (Min.) |
| Display Colors | 16.7M (8-bit), CIE1931110% |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | MIPI (4 data lanes), 44 pins |
| Input Voltage | 2.5/3.1/3.8V (VDD3/VCI/VBAT) |
