| PartNumber | B080UAB01.0 |
| Brand | AUO |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 1200×1920 |
| Composition | Assembly , a-Si TF |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED , 15K hours , No Driver |
| Interface | |
| Manufacturer | AUO |
| Screen Size | 8.0 inch |
| Pixel Number | 1200(RGB)×1920 (WUXGA) 283PPI |
| Active Area(mm) | 107.64 × 172.224 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 350 (Typ.)(cd/m²) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 60% NTSC |
| Mass | - |
| Refresh Rate | 60Hz |
| Model Name | B080UAB01.0 |
| Screen Type | Assembly , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 120.6 × 206.6 × 3.45 (H×V×D) |
| Treatment | Hard coating (7H) |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Work Mode | - |
| Response | 27 (Typ.)(Tr+Tf) ms |
| Used for | Pad & Tablet |
| Touchscreen | On-Cell Touch |
