| PartNumber | B080UAN01.4 |
| Brand | AUO |
| Size | 8.0 |
| Application | PAD |
| Resolution | 1200(RGB)×1920 , WUXGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | AUO |
| Panel Model | B080UAN01.4 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.0 inch |
| Display Mode | AHVA, Normally Black, Transmissive |
| Active Area | 107.64×172.224 mm |
| Outline | 114.6×184.6×3.65 mm |
| Surface | Hard coating (1H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193160% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 7S3PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 45 pins |
| Input Voltage | 3.3V (Typ.) |
