| PartNumber | LQ080Y5DW30 |
| Brand | SHARP |
| Size | 8.0 |
| Application | CNS |
| Resolution | 800(RGB)×480 , WVGA |
| Composition | LCM |
| Brightness | 543 cd/m² (Typ.) |
| CR | |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | SHARP |
| Panel Model | LQ080Y5DW30 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.0 inch |
| Display Mode | ASV, Normally Black, Transmissive |
| Active Area | 174×104.4 mm |
| Surface | |
| Contrast Ratio | |
| Display Colors | 262K (6-bit) |
| Response Time | |
| Viewing Angle | |
| Lamp Type | WLED |
| Signal Interface | Parallel RGB (1 ch, 6-bit) |
