| PartNumber | NDS0708001280-31 |
| Brand | SEBO |
| Size | 7.0 |
| Application | PAD |
| Resolution | 800(RGB)×1280 , WXGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | SEBO |
| Panel Model | NDS0708001280-31 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 7.0 inch |
| Display Mode | Normally Black, Transmissive |
| Active Area | 94.2×150.72 mm |
| Outline | 104.32×161.67×4.19 mm |
| Surface | |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 5S5PWLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 8-bit), 31 pins |
| Input Voltage | 3.3V (Typ.) |
