| PartNumber | B080XAT01.1 |
| Brand | AUO |
| Size | 7.9 |
| Application | PAD |
| Resolution | 768(RGB)×1024 , XGA |
| Composition | Assembly |
| Brightness | 230 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | AUO |
| Panel Model | B080XAT01.1 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Panel Size | 7.9 inch |
| Active Area | 119.808×159.744 mm |
| Outline | 142×205×6.1 mm |
| Surface | |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193150% |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | MIPI (4 data lanes), 35 pins |
| Input Voltage | 3.7V (Typ.) |
