| PartNumber | B101UAN07.2 |
| Brand | AUO |
| Size | 10.1 |
| Application | PAD |
| Resolution | 1200(RGB)×1920 , WUXGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | MIPI |
| Panel Brand | AUO |
| Panel Model | B101UAN07.2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.1 inch |
| Display Mode | AHVA, Normally Black, Transmissive |
| Active Area | 135.36×216.576 mm |
| Outline | 143×227.93×4.3 mm |
| Surface | Glare (Haze 0%), Hard coating |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193171% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 8S4PWLEDWithout Driver |
| Signal Interface | MIPI (4 data lanes), 45 pins |
| Input Voltage | 3.3V (Typ.) |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| B101UAT02.1 | AUO | 10.1 | 1920×1200 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| HJ080NA-04L | Innolux | 8.0 | 1024×768 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LTL120QL01-001 | Samsung | 12.0 | 2160×1440 |
