| PartNumber | B125XTN03.0 |
| Brand | AUO |
| Size | 12.5 |
| Application | Laptop Industrial |
| Resolution | 1366(RGB)×768, WXGA, 125PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | eDP |
| Panel Brand | AUO |
| Panel Size | 12.5" |
| Display Area | 276.615(W)×155.52(H) mm |
| Outline Size | 290.5(W)×181.4(H) ×3(D) mm |
| Viewing Angle | 70/70/55/65 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Display Colors | 262K 45% NTSC |
| Frequency | 60Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | B125XTN03.0 (AUO106C) |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 16 (Typ.)(Tr+Td) |
| Lamp Type | WLED , 15K hours , With LED Driver |
| Touch Screen | Without |
