| PartNumber | B173RW01 V1 |
| Brand | AUO |
| Size | 17.3 |
| Application | NBPC |
| Resolution | 1600(RGB)×900 , HD+ |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | B173RW01 V1 9 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 17.3 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 382.08×214.92 mm |
| Outline | 398.1×232.8×5.8 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193160% |
| Response Time | 2/6 (Typ.)(Tr/Td) |
| Viewing Angle | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| B133XW03 V0 | AUO | 13.3 | 1366×768 |
| B140XTN03.9 | AUO | 14.0 | 1366×768 |
| B156HW03 V0 | AUO | 15.6 | 1920×1080 |
| B156XTN02.4 | AUO | 15.6 | 1366×768 |
| B156XW04 V7 | AUO | 15.6 | 1366×768 |
| HT14P12-100 | HYDIS | 14.1 | 1400×1050 |
| LP141X2 | LG Display | 14.1 | 1024×768 |
| LP156WH4-TLN1 | LG Display | 15.6 | 1366×768 |
| LTN150PF-L02 | Samsung | 15.0 | 1400×1050 |
| LTN156AT02-B04 | Samsung | 15.6 | 1366×768 |
