| PartNumber | BV055HDM-T00 |
| Brand | BOE |
| Size | 5.5 |
| Application | Mobile Phone |
| Resolution | 720×1280 |
| Composition | Assembly, a-Si TFT |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | |
| Interface | |
| Manufacturer | BOE |
| Model Name | BV055HDM-T00 |
| Screen Size | 5.5 inch |
| Screen Type | Assembly, a-Si TFT-LCD |
| Pixel Number | 720(RGB)×1280 (WXGA) 268PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 68.04 × 120.96 (H×V) |
| Outline(mm) | - |
| Luminance | - |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 25/25 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 70% NTSC |
| Mass | - |
| Used for | Mobile Phone |
| Refresh Rate | 60Hz |
| Touchscreen | On-Cell Touch |
| 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| LH550WF4-SJ11 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
