| PartNumber | LQ055T3SX04 |
| Brand | SHARP |
| Size | 5.5 |
| Application | MPH |
| Resolution | 1080(RGB)×1920 , FHD |
| Composition | CELL |
| Brightness | 0 |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Panel Brand | SHARP |
| Panel Model | LQ055T3SX04 |
| Panel Type | IGZO TFT-LCD , CELL |
| Panel Size | 5.5 inch |
| Display Mode | New Mode2, Normally Black, Transmissive |
| Active Area | 68.04×120.96 mm |
| Outline | 70.84×128.16 mm |
| Surface | |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 4.2% (Typ.)(with Polarizer) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193170% |
| Response Time | 35 (Max.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Driver IC | COG Built-in NT35532 |
