| PartNumber | RGS15128128FH035 |
| Brand | RiTdisplay |
| Size | 1.46 |
| Application | MPH |
| Resolution | 128(RGB)×128 |
| Composition | OLED |
| Brightness | 90 cd/m² (Typ.) |
| CR | 2000:1 |
| Colors | 65K/262K |
| Backlight | self |
| Interface | CPU/SPI |
| Panel Brand | RiTdisplay |
| Panel Model | RGS15128128FH035 |
| Panel Type | AM-OLED , OLED |
| Panel Size | 1.46 inch |
| Active Area | 26.279×26.284 mm |
| Outline | 33.5×46.33×1.71 mm |
| Surface | Antiglare |
| Contrast Ratio | 2000 : 1 (Typ.) |
| Display Colors | 65K/262K , CIE193166% |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 105Hz |
| Driver IC | Built-in SSD1351 |
| Signal Interface | 8/16/18-bit 6800/8080 parallel, SPI, 37 pins |
| Input Voltage | 16.5V (Typ.)(VCC) |
