| PartNumber | DLC0283FZG-7 |
| Brand | Other |
| Size | 2.8 |
| Application | MPH |
| Resolution | 240(RGB)×320 , QVGA |
| Composition | LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | CPU/RGB |
| Panel Brand | DLC |
| Panel Model | DLC0283FZG-7 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 2.8 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 43.2×57.6 mm |
| Outline | 50×70 mm |
| Surface | |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 262K , CIE193150% |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 5S1PWLEDWithout Driver |
| Signal Interface | CPU/RGB, 39 pins |
| Input Voltage | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| 28QVF2H | SII | 2.8 | 240×320 |
| AMEJ006 | Samsung | 2.8 | 240×400 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B7UX01 | SHARP | 2.8 | 240×400 |
| PJ028MA-01A | Innolux | 2.8 | 240×320 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| UG-5664ALBDF01 | WiseChip | 2.8 | 256×64 |
| AMS465GS53 | Samsung | 4.7 | 720×1280 |
| H027QT01 | AUO | 2.7 | 208×320 |
| LB020Q01-A1 | LG Display | 2.0 | 320×240 |
| LH550WF2-SD03 | LG Display | 5.5 | 1080×1920 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| LS035Y8DX02A | SHARP | 3.5 | 480×800 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| LS055T1SX01 | SHARP | 5.5 | 1080×1920 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
