| PartNumber | TM028HBHG02 |
| Brand | Tianma |
| Size | 2.8 |
| Application | MPH |
| Resolution | 240(RGB)×320 , QVGA |
| Composition | LCM |
| Brightness | 210 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | CPU |
| Panel Brand | TIANMA |
| Panel Model | TM028HBHG02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 2.8 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 43.2×57.6 mm |
| Outline | 50×69.2×4.4 mm |
| Surface | Clear |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193165% |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lamp Type | 1S4PWLEDWithout Driver |
| Signal Interface | 8/16-bit 6080/8080 parallel, 37 pins |
| Input Voltage | (1.8/2.8)/2.8V (Typ.)(VCC/VCI) |
