| PartNumber | C-51505NFQJ-LG-AKN |
| Brand | Kyocera |
| Size | 3.0 |
| Application | |
| Resolution | 20×2 |
| Composition | LCM |
| Brightness | |
| CR | 80:1 |
| Colors | Monochrome |
| Backlight | G-LED |
| Interface | CPU |
| Panel Brand | Kyocera |
| Panel Model | C-51505NFQJ-LG-AKN 1 Compatible model |
| Panel Type | FSTN-LCD , LCM |
| Panel Size | 3.0 inch |
| Display Format | 20 characters × 2 lines |
| Display Mode | STN, Black/White (Negative), Transmissive |
| Display Fonts | 5×8 dots |
| Character Size | 3.235×5.585 mm |
| Character Pitch | 3.8×5.95 mm |
| Active Area | 75.435×11.535 mm |
| Bezel Area | 83.0×18.6 mm |
| Outline | 116×37×15.9 mm |
| Contrast Ratio | 80:1 (Typ.) |
| Display Colors | Monochrome |
| Response Time | 45/200 (Typ.)(Tr/Td) |
| Lamp Type | 1 pcsG-LEDWithout Driver |
| Signal Interface | 8-bit parallel, 16 pins |
| Input Voltage | 5.0V (Typ.) |
